Flemming R. Ovesen / Torben Taustrup



Venus





Venus transit June 8th 2004

Technical data:
June 8. - 07:59 UT. Eyepiece projection. Canon PowerShot A80 shot thru 4"- f/15 Jaeger refractor equiped with Baader solar filter and 25 mm Meade eyepiece. A couple of  fairly small sunspots can be seen at the upper part of image.







Technical data:
February 15. - 16:05 UT. Eyepiece projection, focal length 9.9 meters (F:49). Cookbook CCD camera. Resolution: 252 x 242. Exposure time: 1/1000 sec. This is a 13 image stack.

Planet angular diameter: 35,45". Magnitude: -4,6






Technical data:
March 5. - 18:05 UT. Eyepiece projection, focal length 9.9 meters (F:49). Cookbook CCD camera. Resolution: 252 x 242. Exposure time: 1/1000 sec. This is an 11 image stack.

Planet angular diameter: 46,83". Magnitude: -4,6



Technical data:
March 21. - 17:06 UT. Eyepiece projection, focal length 9.9 meters (F:49). Cookbook CCD camera. Resolution: 252 x 242. Exposure time: 1/200 sec. Filter: H-Alpha pass. This is a 4 image stack.

Planet angular diameter: 57,27".
3.57% illuminated.
Magnitude: -4,2
